Technical details |
---|
Status | Launched |
Launch date | Q1'25 |
Processor |
---|
AI software frameworks supported by CPU | Windows ML, WebNN, OpenVINO, DirectML, ONNX RT |
Efficient-core boost frequency | 4.6 GHz |
Efficient cores | 12 |
Processor generation | Intel Core Ultra (Series 2) |
Processor base power | 65 W |
Performance cores | 8 |
Maximum number of DMI lanes | 8 |
Performance-core boost frequency | 5.2 GHz |
Performance-core base frequency | 2.4 GHz |
Maximum turbo power | 182 W |
Efficient-core base frequency | 1.8 GHz |
Processor manufacturer | Intel |
Processor cache type | Smart Cache |
Processor socket | FCLGA1851 |
Processor family | Intel Core Ultra 7 |
Processor cache | 30 MB |
Processor ARK ID | 241064 |
Processor operating modes | 64-bit |
Processor codename | Arrow Lake |
Processor threads | 20 |
Processor boost frequency | 5.3 GHz |
Processor cores | 20 |
Processor model | 265F |
Box | Yes |
Graphics |
---|
Discrete graphics card | No |
Discrete graphics card model | Not available |
On-board graphics card model | Not available |
On-board graphics card | No |
Features |
---|
Direct Media Interface (DMI) Revision | 4.0 |
Use conditions | PC/Client/Tablet |
Maximum number of PCI Express lanes | 24 |
Market segment | Desktop |
PCI Express slots version | 5.0, 4.0 |
Thermal Monitoring Technologies | Yes |
Idle States | Yes |
Supported instruction sets | SSE4.2, AVX 2.0, SSE4.1 |
Scalability | 1S |
Embedded options available | No |
Execute Disable Bit | Yes |
Memory |
---|
Memory channels | Dual-channel |
Memory clock speeds supported by processor | 6400 MHz |
Maximum internal memory supported by processor | 192 GB |
Memory types supported by processor | DDR5-SDRAM |
Processor special features |
---|
Intel® Speed Shift Technology | Yes |
Intel® Control-flow Enforcement Technology (CET) | Yes |
Intel® Turbo Boost Max Technology 3.0 frequency | 5.3 GHz |
Intel® Boot Guard | Yes |
Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
Intel® Thunderbolt 4 | Yes |
Intel® Thread Director | Yes |
Mode-based Execute Control (MBE) | Yes |
Intel® Standard Manageability (ISM) | Yes |
Intel Turbo Boost Max Technology 3.0 | Yes |
Intel® Volume Management Device (VMD) | Yes |
Intel VT-x with Extended Page Tables (EPT) | Yes |
Intel® OS Guard | Yes |
Intel Trusted Execution Technology | Yes |
Intel® AES New Instructions (Intel® AES-NI) | Yes |
Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Intel Virtualization Technology (VT-x) | Yes |
Intel® Turbo Boost Technology | 2.0 |
Intel 64 | Yes |
Enhanced Intel SpeedStep Technology | Yes |
Intel® Secure Key | Yes |
Other features |
---|
L2 cache | 36864 KB |
Maximum internal memory | 192 GB |
Safety warning |
---|
Warnings | Do not touch the processor pins to avoid electrostatic damage. |
Neural processor unit (NPU) |
---|
AI software frameworks supported by NPU | Windows ML, WebNN, ONNX RT, OpenVINO, DirectML |
Windows Studio effects support | Yes |
NPU performance up to | 13 TOPs |
Neural processor unit (NPU) | Intel AI Boost |
Sparsity support | Yes |
Total processor performance up to | 25 TOPs |
